This switch provides an embedded HTML web site residing in flash
memory. It offers advanced management features and allows users
to manage the SmartGST-801M from anywhere on the network
through a standard browser such as Microsoft Internet Explorer.
SNMP Network Management
SNMP (Simple Network Management Protocol) provides
monitoring and control of network devices. It manages
configurations, statistic collection, performance, and security.
2.
Hardware Description
This section describes the switch hardware. The SmartGST-801M is
a 19" rack mountable switch with eight 100Mbps Fiber ports and one
GBIC port
The physical dimensions of the SmartGST-801M are:
440mm x 160mm x 44mm (L x W x H)
Front Panel
The Front Panel of the SmartGST-801M consists of eight 100Mbps
Fast Ethernet Fiber and one GBIC port. LED indicators are located on
the front panel of the switch.
Figure 2-1. The Front Panel of theSmartGST-801M
