Model 5100-02-IT Combustible Gas Sensor Module
Page: 26
7. SERVICE
7.1 MODULE SUB ASSEMBLY
NOTE
Area must be determined to be non-hazardous before opening enclosure.
7.2 ENCLOSURE REPLACEMENT
The enclosure should be replaced if the cover threads or conduit threads have been damaged, or if the
enclosure has been damaged sufficiently that it no longer meets the required NEMA classification.
To replace the enclosure follow the transmitter and sensor assembly removal instructions, remove the
damaged enclosure from its conduit, install a new enclosure and continue the transmitter and sensor
assembly replacement instructions.
Figure 7 - 1: Module Components
