REVERSING THE DOOR

All U-Line units (except Stainless Steel models) may be left or right hand
opening. The door opening is easily reversed by moving the hinge hard-
ware to the opposite side (see Figure 10). To reverse the door:

Figure 10

UL318B

1. Remove top hinge screw pin

(7/64" Allen wrench) from
cabinet (see Figure 11).
Remove door by tilting forward
and lifting off bottom hinge pin.

Figure 11

UL310
