CONNECTING A DRAIN PUMP
If a gravity drain connection is not available, and you have not pur-
chased the CLR2060 with factory installed pump, we strongly rec-
ommend the use of the U-Line P60 drain pump. The U-Line P60 drain
pump is available through your Dealer, or direct from U-Line with com-
plete installation instructions. If a pump other than the U-Line P60
drain pump is to be used, it must meet the following specifications:
• It must be UL listed and have a UL listed, 120 VAC, 3-wire ground-
ed power cord.
• It must have overall maximum outside dimensions of 8-3/4" wide x
5-3/4" deep x 7-3/4" high.
• It must have a minimum flow rate of 15 gallons per hour at 10 feet
of lift.
• It must have a sealed sump which does not allow water leakage in
the case of a power outage, restricted drain or pump failure.
• It must have a check valve in the discharge line to prevent waste
water return to the pump.
• It must have an overflow protection control which will shut off power
to the ice maker in the event of a pump failure.
• It must have an operating temperature range of 50°F to 110°F
(10°C to 40°C).
In the event of a power outage, restricted drain or pump
failure, the failure to use the U-Line P60 drain pump or a
pump with the above listed specifications, could result in
substantial water leakage and pooling with severe and cost-
ly water damage and related consequential damages and
harm.
CAUTION
8
