Assembly Section 2-5
ASSEMBLY
WEATHER-PACK/METRI-PACK ASSEMBLY
These instructions apply to both Weather-Pack and Metri-pack connectors.
NOTE: Use the specific tool for the type of connector you are assembling.
1. Apply seal to cable, before stripping
insulation. 2. Align seal with cable insulation.
3. Put terminal in crimping tool, then
position wire and seal in place. 4. Crimp and visually inspect for a good
crimp before installing in connector body.
