Page 107
Parts Section 5-23
ITEM
PART NO.
QTY.
DESCRIPTION
1
06510026
1
COOLER,SNGL FAN,350BTU
06510029
AVAIL.
FAN ASSY,COOLERS,06510025-26
2
06370012
1
COOLER MNT,RH,FRNT,PMP MNT
3
06370013
1
COOLER MNT,LH,FRNT,PMP MNT
4
21835
4
CAPSCREW,3/4 X 2-3/4 NC
5
22021
4
FLATWASHER,3/4
6
21993
4
LOCKWASHER,3/4,GR 8
7
21825
4
HEX NUT,3/4 NC
8
32876
1
GAURD, TNDM PUMP, UNIVERSAL
9
21529
10
CAPSCREW,1/4 X 3/4NC
10
21986
10
LOCKWASHER,1/4
11
22014
10
FLATWASHER,1/4
12
35176
10
U-NUT,1/4,3/4 TO CENTER
13
06370015
1
SCREEN,COOLER,FRNT
14
34117
2
ELBOW,1MOR X 1MJ90,FORGED
15
32408
1
PUMP MTG BRKT,FD81-8560
TWIN ROTARY, TRR
16
06500099
1
HOSE,1x31(20FLG90x1FJX)
17
06500100
1
HOSE,1x246(1FJXx1FJX)
TWIN ROTARY, TRAILKAT
16A
06500102
1
HOSE,1 1/4x31(24FLG90x1FJX)
17A
06500103
1
HOSE,1x242(1FJXx1MJ)
R 8-98
HYDRAULIC COOLER ASSEMBLY, CAB
