Twin Rotary Common Section 6-7
TRAILKAT® REAR ROTARY DECK ASSY
ITEM PART NO. QTY. DESCRIPTION
1 06320002 1 TRAILKAT®,60,WLDMNT
2 6T0112 2 SHACKLE,W/PIN,CPLT
3 22051 1 CABLE,LIFT,TRR,60
4 TB1033 2 PIN,CLEVIS,1 x 4
5 06537021 4 ROLLPIN,5mm x 50mm,SS
6 21474A 1 HITCH,3PT,TRR
7 28511 1 STAND,SAFETY SUPPORT W/PAD
8 23329 1 CASTER WHL,SOLID TIRE W/SPIND
9 22057 1 SPINDLE,CASTER AXLE,ASSY
10 22018 2 FLATWASHER,1/2,WIDE
11 21725 2 HEX NUT,1/2,NC
12 6T3211 1 GREASE ZERK,1/8
13 06370003 1 CASTER ADJ,TRAILKAT
14 06504016 1 MOTOR,M365-1 1/4”,SPLINE,SEALED
15 6T1025 4 CAPSCREW,1/2 x 2,NC,GR8
16 06533004 12 FLATWASHER,1/2,SAE,GR8
17 21738 2 CAPSCREW,1/2 x 3-1/4,NC
18 06370004 1 CASTER MNT,TRAILKAT
19 21700 4 HEX NUT,1/2,NF
20 21990 4 LOCKWASHER,1/2
21 06420003 2 U-BOLT,.50 x 3.25 x 5.00
22 21625 22 HEX NUT,3/8,NC
23 21988 8 LOCKWASHER,3/8
24 21631 4 CAPSCREW,3/8 x 1-1/4,NC,GR8
25 34972 4 PLATE,CAP,CHAIN
26 34974 2 ROD,CHAIN,INNER,TM60
27 06420005 2 U-BOLT,.38 x 5.63 x 6.31
28 34973 2 ROD,CHAIN,OUTER,TM60
29 06410254 2 SKID SHOE,TSR
30 22992 156 CHAIN,10 LINK
31 33698 2 PIN,1.13 x 9.00
32 33699 2 PIN,1 x 8.88
33 TF1143 4 LYNCH PIN
34 34980 1 SPINDLE ASSY,TM60
35 06320011 2 SPACER,TSR,SPINDLE
36 06530221 8 CAPSCREW,1/2 x 2-1/4,NF,GR8
37 SEE ROTARY KNIVES & DISC PAGE
38 SEE ROTARY KNIVES & DISC PAGE
39 SEE ROTARY KNIVES & DISC PAGE
40 SEE ROTARY KNIVES & DISC PAGE
41 SEE ROTARY KNIVES & DISC PAGE
42 6T2290 6 CAPSCREW,5/8 x 2,NF,GR8
43 25270 6 FLATWASHER,5/8,USS,GR8
44 6T2270 14 PLOW BOLT,3/8 x 1,NC
45 22016 14 FLATWASHER,3/8,GR8
