Tiger Products Co., Ltd 6020009 User Manual
Page 137
Twin Rotary Common Section 6-23
3 SP HUSCO - LOAD SENSE COMBO (06502044)
ITEM
PART NO. QTY
DESCRIPTION
1
31595
1
INLET END COVER
2
31594
1
END COVER, LOAD SENSE
3
31597
1
VALVE SECTION (DOUBLE ACTING, CENTER SPRING)
4
31597
1
VALVE SECTION (DOUBLE ACTING, CENTER SPRING)
5
31597
1
VALVE SECTION (DOUBLE ACTING, CENTER SPRING)
(REMOVE SHUTTLE DISC)
6
06503067
1
RELIEF PLUG
7
31861
1
RELIEF VALVE, 360 PSI
8
28816
1
RELIEF VALVE, 1812 PSI
9
06503068
1
RELIEF PLUG
10
6T4209
1
RELIEF PLUG
11
31862
1
RELIEF VALVE, 2175 PSI
12
31862
1
RELIEF VALVE, 2175 PSI
13
28816
1
RELIEF VALVE, 1812 PSI
14
31593
3
VALVE SEAL KIT (FOR ONE SECTION)
14A
2
WIPER
14B
2
O-RING SMALL
14C
1
O-RING LARGE
14D
1
SHUTTLE DISC
14E
1
SPRING
15
TB1017L
3
LEVER KIT (FOR ONE SECTION)
15A
1
LEVER KNOB
15B
1
LEVER
15C
2
LEVER WASHER
15D
1
LEVER CLIP
15E
2
LINKAGE
15F
1
LEVER PIN
15G
1
ROLL PIN
15H
1
LEVER BOOT
15J
1
LEVER BOLT
15K
1
LEVER DUST COVER
15L
1
LEVER NUT
16
31603
3
COMPENSATOR
17
23397
1
TIE ROD KIT
18
24214
1
O-RING, LARGE
