Parts Section 5-19
COMBO LIFT VALVE - 3SP, CAB/WOC
ITEM PART NO. QTY. DESCRIPTION
1 31324 1 VALVE,3SP,HSC,TRR, COMBO,LS
2 34622 1 VALVE MOUNTING PLATE
3 06340008 1 VALVE MOUNTING ANGLE, LF
4 06340009 1 VALVE MOUNTING ANGLE, RF
5 06510027 1 SWTCHBX ASSY,TWIN/T3F,REV FAN
6 23865B 1 CABLE CONTROL MOUNTING BRACKET
7 6T1251 2 CABLE CONTROL BOX
8 34623 2 CONTROL CABLE 122”
9 30750A 1 SUPPORT BRACKET
10 21544 3 CAPSCREW 1/4” X 5“
12 21635 3 CAPSCREW 3/8” X 2 1/4”
14 22016 3 FLATWASHER 3/8”
15 21627 3 NYLOCK NUT 3/8”
16 6T3200 1 SPLIT HOSE 6” LONG
17 TB3440 8” TRIM LOCK
18 21986 5 LOCKWASHER 1/4”
19 21525 3 HEX NUT 1/4”
20 23113 1 CAPSCREW 10MM X 30MM (1.5 PITCH)
22 6T4411 2 CABLE CLEVIS
23 21500 4 HEX NUT 1/4” UNF
24 6T3017 2 ROLL PIN
25 06500063 1 HOSE,1/2x30(3/4FJX90x1/2FJX90L)195deg (RETURN)
26 06500064 1 HOSE,1/4x18(3/8ORB90x5/16FJX) (LOAD SENSE)
27 06500062 1 HOSE,1/2x30(1/2FJX90 x 1/2FJX90L) 195 (PRESSURE)
28 34631 2 HOSE, 1/4x126(3/8FJXx3/8FJX90)
29 34633 1 HOSE,1/4x66(3/8FJ90x 1/2ORB90)90
30 33492 1 HOSE,1/4X138(3/8FJX90X3/8FJX)
31 34634 1 HOSE,1/4x66(3/8FJ90x 1/2ORB90)180
32 33271 2 ADAPTER,1/2 MOR X 3/8 MJ
33 06503012 1 ADPTR,27MMORBx3/4MJ
34 06503011 2 ADAPTER,5/8ORBx1/2MJ
36 33463 1 ADAPTER
37 21631 4 CAPSCREW 3/8” X 1-1/4”
38 21988 8 LOCKWASHER 3/8”
39 21625 8 HEX NUT 3/8”
40 21630 4 CAPSCREW 3/8” X 1”
41 21990 2 LOCKWASHER 1/2
43 06503002 1 ADAPTER,12MM ORBx5/16MJ
49 21729 2 CAPSCREW 1/2” X 1” NC
50 22016 4 FLATWASHER 3/8”
** 34618 38” HOSE SLEEVE (NOT SHOWN)
