Page 39: Operations, How to use the jpeg conversion tool (continued)
77
Operations
76
Setting up the projector using a Web browser
■
How to use the “Projector Configuration Tool”
The “Projector Configuration Tool” uses the Web server features of the projector to
set up the projector using a wireless LAN USB adapter.
When using the “Projector Configuration Tool”, set up the wireless LAN connecting
the projector and the computer.
1
See “Checking the projector status”
to display
information on the screen and write down the IP address.
2
Invoke Internet Explorer.
Internet Explorer Ver. 6.0 is recommended. Enable the Javascript functions.
* Toshiba does not guarantee the operation for later versions.
3
In the address bar, enter the IP address
“http://xxx.xxx.xxx.xxx/” recorded in step
1
above.
The Web browser will then display the following page.
Projector name
Projector ID
Menu
Note 1: To prevent access from third parties, the projector is restricted to permit access
only from the computer that has been set up for the TCP/IP to have the same
network address as the projector.
Note 2: If you use a proxy server, do not enable the proxy when accessing the above IP
address.
When the wireless LAN is set to use Ad hoc mode, use the WEB browser function
in the Easy Connect menu of Wireless Utility.
Note
• This function can be enabled using the WEB Browser function in the Easy Connect menu
of Wireless Utility without specifying the URL into the browser s address bar.
■
Making a presentation with converted JPEG files
(1) Copy the folder created by the JPEG Conversion Tool, or its contents, onto a USB
memory.
(2) Use the step
1
in “Playing a slide show from a thumbnail list”
to display a
list of thumbnails.
(3) Follow the instructions in step
2
in “Playing a slide show from a thumbnail list”
to find the thumbnail of the first slide, Slide001.jpg, and move the orange
frame to it. (Select Slide001.jpg)
(4) Press the
button on the remote control. An enlarged view of the first slide
appears on the screen. This starts the presentation.
(5) To continue to the next slide, click on the remote control’s
button. To go back to
the previous slide, click on the
button.
■
Creating a screen capture and converting it into a JPEG file
This function saves the current computer screen as a JPEG file.
(1) In the Conversion Method field, select Creating screen
capture.
(2) In the File settings field, click on the Browse button for File
name after conversion.
The Save As dialog box appears.
(3) In the Save As dialog box:
(a) Specify the location in which to save the converted file;
(b) Enter a file name of up to 8 characters in the File Name
field; and
(c) Click on the Save button.
(4) (a) In the JPEG Conversion Tool window, click on the
Conversion button.
(b) A confirmation message appears. Click Yes.
The computer creates a screen capture, and
converts it into a JPEG file in the specified location.
When it is finished, a message appears to tell you
that a “JPEG file has been created”.
Note
• The maximum resolution of JPEG files created with the JPEG Conversion Tool is 1,024
×
768 pixels.
(1)
(1)
(2)
(2)
(4)-(a)
(4)-(a)
(3)-(b)
(3)-(c)
(3)-(a)
(4)-(b)
(4)-(b)
How to use the JPEG Conversion Tool (Continued)
