3.5 Replacing the SATA backplane
Chapter 3: Replacing pre-installed components 41
2. Remove the power and data cables from the floppy disk
drive.
3. Loosen the two retaining screws that secures the floppy
disk drive in place.
4. Slide the disk drive from the chassis.
5. Slide the new unit into place, secure with the retaining
screw and replace the power and data cables.
3.5 Replacing the SATA backplane
This section describes how to replace the SATA backplane
on your B4881V50S4H.
1. Remove the chassis cover. See Removing the chassis
cover on page 13.
