5.9 Transmit Interrupt Status (Masked) Register (TXINTSTATMASKED)
EMAC Port Registers
The transmit interrupt status (Masked) register (TXINTSTATMASKED) is shown in Figure 37 and
described in Table 37 .
Figure 37. Transmit Interrupt Status (Masked) Register (TXINTSTATMASKED)
31 16
Reserved
R-0
15 8 7 6 5 4 3 2 1 0
Reserved TX7 TX6 TX5 TX4 TX3 TX2 TX1 TX0
PEND PEND PEND PEND PEND PEND PEND PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R/W = R = Read only; -n = value after reset
Table 37. Transmit Interrupt Status (Masked) Register (TXINTSTATMASKED) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved
7 TX7PEND TX7PEND masked interrupt read
6 TX6PEND TX6PEND masked interrupt read
5 TX5PEND TX5PEND masked interrupt read
4 TX4PEND TX4PEND masked interrupt read
3 TX3PEND TX3PEND masked interrupt read
2 TX2PEND TX2PEND masked interrupt read
1 TX1PEND TX1PEND masked interrupt read
0 TX0PEND TX0PEND masked interrupt read
Ethernet Media Access Controller (EMAC)/Management Data Input/Output (MDIO) 92 SPRU975B – August 2006
