4.11 MDIO User Command Complete Interrupt Mask Clear Register (USERINTMASKCLEAR)
MDIO Registers
The MDIO user command complete interrupt mask clear register (USERINTMASKCLEAR) is shown in
Figure 25 and described in Table 24 .
Figure 25. MDIO User Command Complete Interrupt Mask Clear Register (USERINTMASKCLEAR)
31 16
Reserved
R-0
15 2 1 0
Reserved USERINTMASK
CLEAR
R-0 R/WC-0
LEGEND: R = Read only; R/WC = Read/Write 1 to clear; -n = value after reset
Table 24. MDIO User Command Complete Interrupt Mask Clear Register (USERINTMASKCLEAR)
Field Descriptions
Bit Field Value Description
31-2 Reserved 0 Reserved
1-0 USERINTMASK MDIO user command complete interrupt mask clear for USERINTMASKED[1:0] respectively.
CLEAR Setting a bit to 1 will disable further user command complete interrupts for that particular
USERACCESS register. Writing a 0 to this register has no effect.
