www.ti.com
4.8 MDIO User Command Complete Interrupt (Unmasked) Register (USERINTRAW)
MDIO Registers
The MDIO user command complete interrupt (unmasked) register (USERINTRAW) is shown in Figure 22
and described in Table 21 .
Figure 22. MDIO User Command Complete Interrupt (Unmasked) Register (USERINTRAW)
31 16
Reserved
R-0
15 2 1 0
Reserved USERINTRAW
R-0 R/WC-0
LEGEND: R = Read only; R/WC = Read/Write 1 to clear; -n = value after reset
Table 21. MDIO User Command Complete Interrupt (Unmasked) Register (USERINTRAW) Field
Descriptions
Bit Field Value Description
31-2 Reserved 0 Reserved
1-0 USERINTRAW MDIO User command complete event bits. When asserted, a bit indicates that the previously
scheduled PHY read or write command using that particular USERACCESS register has
completed. Writing a 1 will clear the event and writing 0 has no effect.
SPRU975B – August 2006 Ethernet Media Access Controller (EMAC)/Management Data Input/Output (MDIO) 73
