2
Chapter 2 Chapter 2 Chapter 2 Chapter 2
Hardware installation
This chapter covers inserting your Ethernet Card in the notebook’s
PCMCIA port, and connecting the card to a network.
What’s in the package
Please ensure that the following items are included in your pack-
age. If any items are missing, contact your dealer.
•
PCMCIA 10/100 Mbps Ethernet Card
•
RJ-45 adapter
•
Software and device driver disk
•
This user’s manual
Hardware description
The Ethernet Card is encased in a stainless compact frame and has
a 68-pin connector for attaching to the notebook’s PCMCIA port,
and a 15-pin flat connector for connecting to the Ethernet adapter.
