Appendix C
Appendix C
Appendix C
Appendix C
Specifications
Standards Compliance:
IEEE 802.3 10Base-T, 802.3u 100Base-TX
Card Size:
5.0mm Type II
Connection Mode:
Full or Half duplex for both 10 and 100 Mbps
Media Supported:
Category-3,4,5 for 10Base-T
Category 5 for 100Base-TX
Operating Distance:
100m maximum hub-to-node distance
Network Interface:
Female
RJ-45 connector
Socket Interface:
68-pin 16-bit PCMCIA socket connector
Operating Temperature:
10ºC to 50ºC
Certification:
FCC/VCCI/CE Class B
Dimensions:
85.6 x 54 x 5 mm
Power Consumption:
5V power supply and 3.3V operation
750mW/10 Mbps mode, 1150mW/100 Mbps mode
