25
8.2 Power Range 1000-3000 VA (230V)
Tower International
230V Model
UT1E1E010C6 UT1E1E015C6 UT1E1E020C6 UT1E1E030C6
Rack-
mount
(2U) International
230V Model UT1E1E010C6R
KB2 UT1E1E015C6R
KB2 UT1E1E020C6R
KB2 UT1E1E030C6R
KB2
Input Voltage
(International)
230 VAC (161 – 276 V)
Voltage Range
(International)
+20% to -30%
Capacity (VA) 1000 VA 1500 VA 2000 VA 3000 VA
Capacity (W) 700 W 1050 W 1400 W 2100 W
Frequency 50 / 60 Hz auto sensing
Power Factor Greater than 0.97
Topology True on-line, Double conversion Input PF correction
Output Voltage
(International)
230 VAC
Frequency 50 / 60 Hz auto sensing
Wave Form Sine wave, zero transfer time
Load Power
Factor
0.70
Efficiency
AC/DC/AC
Greater than 86%
Rated Current
(International)
4.3 A 6.5 A 8.7 A 13 A
Overload
Capacity
125% for 1 min., 150% for 10 sec.
Crest Factor 3.0 at full load
Battery DC Voltage
(Tower & 2U)
36 V / 12 V 9 AH x 3 72V / 12 V
7.2AH x 6
72V / 12 V 9AH x
6
Backup Time
(Tower & 2U)
7 min
(full load)
6 min
(full load)
7 min
(full load)
6 min
(full load)
Interface RS-232 and USB standard RemotEye II® and EMD option
Physical Dimensions
(Tower)
16.5”L x 6.0”W x 9.4”H 16.7" L x 8.9" W x 14.2" H
Dimensions
(2U)
16.7”L x 16.9”W x 3.5”H "25.0""L x 16.9""W x 3.5""H"
Weight
(Tower/2U)
35.6 lbs /
37.6 lbs
37.4 lbs /
37.6 lbs
68.4 lbs /
69.5 lbs
72.6 lbs / 71.5 lbs
Line Cord
(International)
IEC 320
Receptacles
(Tower/2U)
International
IEC 320 (4 / 4) IEC 320 (8 / 8)
Environ-
ment Operating
Temperature 0 - 40°C (32 - 104°F)
Altitude 11500 ft (3500 m) above sea level
Warranty Three years on electronics
Two years full replacement on battery (See Toshiba warranty policy for full details.)
Standards - Safety: EN50091-1-1, Emissions: EN50091-2, Immunity: EN50091-2 B (1000-1500VA)
