12
Operating Procedures Models 382/RC25
Section 6 Operating Procedures
We begin our instructions at the point where the parts
are disassembled and laid out to dry from the previous
night’s cleaning.
The following procedures will explain how to assemble
the parts into the freezer, sanitize them, and prime the
freezer with fresh product.
If you are disassembling the machine for the first time
or need information to get to this starting point in our
instructions, turn to “Disassembly” on page 20, and
start there.
Assembly
MAKE SURE THE CONTROL SWITCH IS IN
THE “OFF” POSITION. Failure to do so may result in
personal injury or component damage.
Note: When lubricating parts, use an approved food
grade lubricant (example: Taylor Lube HP). Every
three months discard rubber parts and install new
rubber parts.
Step 1
Install the beater drive shaft. Lubricate the groove
and shaft portion that comes in contact with the rear
shell bearing on the beater drive shaft. DO NOT
lubricate the hex end of the drive shaft.
Slide the seals over the shaft until they snap into their
grooves. Fill the inside portion of the seal with lubricant
and evenly lubricate the flat side of the seal that fits
onto the rear shell bearing.
Figure 5
Install the drive shaft into the freezing cylinder, hex end
first. The drive shaft seal must fit securely over the rear
shell bearing. Be certain the drive shaft fits into the
drive coupling without binding.
Figure 6
Step 2
Install the beater assembly. First check scraper
blades for any nicks or signs of wear. If any nicks are
present or if the blades are worn, replace the blades.
Figure 7
