TFM-PCIV92A User’s Guide
_________________________________________________________________________________________________________________________
- 23 - Rev.1.00.2.1.34
= 101 X2 is selected
= 110 X3 is selected
= 111 X4 is selected
Bit 7 = 0 33/67 M/B ratio is selected(&P1, &P2)
= 1 39/61 M/B ratio is selected(&P0)
S28* Control V.34 modulation 1 0-1 -
= 0 Disables V.34 modulation
= 1 Enables V.34 modulation
S30* Inactivity timer 0 0-255 minute
S32* Synthetic ring volume 10 0-255 -
S33* Synthetic ring frequency 0 0-5 -
S35* Data calling tone 0 0-1
= 0 Disables data calling
= 1 Enables data calling
S37* Maximum line speed attempted 0 0-19 -
= 0 Auto rate
= 1 Reserved
= 2 1200/75 bps
= 3 300 BPS
= 4 Reserved
= 5 1200 BPS
= 6 2400 BPS
= 7 4800 BPS
= 8 7200 BPS
= 9 9600 BPS
= 10 12000 BPS
= 11 14400 BPS
= 12 16800 BPS
= 13 19200 BPS
= 14 21600 BPS
= 15 24000 BPS
= 16 26400 BPS
= 17 28800 BPS
= 18 31200 BPS
= 19 33600 BPS
S38* K56flex downstream rate 1 0-14 -
= 0 Disables K56flex
Register Function Default Range Units
TFM-PCIV92A User’s Guide
_________________________________________________________________________________________________________________________
- 24 - Rev.1.00.2.1.34
= 1 Auto rate
= 2 32K BPS
= 3 34K BPS
= 4 36K BPS
= 5 38K BPS
= 6 40K BPS
= 7 42K BPS
= 8 44K BPS
= 9 46K BPS
= 10 48K BPS
= 11 50K BPS
= 12 52K BPS
= 13 54K BPS
= 14 56K BPS
S48* Error control feature 7 7,128 -
= 7 Negotiation enabled
= 128 Negotiation disabled
S89* Sleep mode timer 10 0,5-65 second
S108 * Network codec type 7 7,22,33 -
= 7 Specified by central site mode
= 22 u-law
= 33 A-law
Notes : The value of the S-registers marked with (*) were saved in NVRAM
