TFM-PCIV92A User’s Guide
_________________________________________________________________________________________________________________________
- 21 -
Rev.1.00.2.1.34
n = 14
44000 BPS
n = 15
45333 BPS
n = 16
46666 BPS
n = 17
48000 BPS
n = 18
49333 BPS
n = 19
50666 BPS
n = 20
52000 BPS
n = 21
53333 BPS
-V90?
Reports current V.90 setting
\A0
Set maximum MNP block size to 64 characters
\A1
Set maximum MNP block size to 128 characters
\A2
Set maximum MNP block size to 192 characters
\A3
Set maximum MNP block size to 256 characters
\Bn
Transmit break in n*100ms (n = 0-9)
\G0
Disables XON/XOFF flow control between local and remote modems
\G1
Enables XON/XOFF flow control between local and remote modems
\J0
Disables DTE speed adjust
\J1
Enables DTE speed adjust
\Kn
Set break control (n=0-5, default is 5).
\N0
Select normal mode
\N1
Select normal mode
\N2
Select MNP reliable mode
\N3
Select V.42 auto-reliable mode
\N4
Select V.42 reliable mode
\Q0
Disables flow control
\Q1
Enables XON/XOFF software flow control
\Q2
Enables CTS hardware flow control
\Q3
Enables CTS/RTS hardware flow control
\Tn
Set inactivity timer in minutes(n=0-255, default is 0)
\V0
Disables protocol result code appended to DCE speed
\V1
Enables protocol result code appended to DCE speed
\X0
Process XON/XOFF character as flow control character only
\X1
Process XON/XOFF character as flow control character and pass through to local DTE
or remote modem
Notes:
The default setting of commands is in bold Italic text format.
AT Command prefix
TFM-PCIV92A User’s Guide
_________________________________________________________________________________________________________________________
- 22 -
Rev.1.00.2.1.34
Appendix 3
S-Register Summary
S0*
No. of rings to start auto-answer 0
0-255
ring
S1*
Ring
count
0
0-255
ring
S2*
Escape
character
43
0-255
ASCII
S3
Carriage
return
character
13
0-127
ASCII
S4
Line
feed
character
10
0-127
ASCII
S5
Backspace character
8
0-32,127
ASCII
S6*
Wait
before
dialing
2
2-65
second
S7*
Wait
for
carrier
50
1-255
second
S8*
Pause
time
for
dial
modifier
,
2
0-65
second
S10*
Lost carrier hang up delay
20
1-254
0.1second
S11*
DTMF
dialing
speed
95
50-150
msec
S12*
Escape
guard
time
50
0-255
20
msec
S14*
Bit-mapped
register
-
0-255
-
Bit 0,1,2
Reserved
Bit 3
= 0 V0 is selected
= 1 V1 is selected
Bit 4,5
Reserved
Bit 6
=
0
10 PPS pulse dialing(&P0, &P1)
=
1
20 PPS pulse dialing(&P2)
Bit
7
Reserved
S21*
Bit-mapped
register
-
0-255
-
Bit0,1,2
Reserved
Bit 4-3
=
00 &D0 is selected
=
01 &D1 is selected
= 10 &D2 is selected
=
11 &D3 is selected
Bit 5
=
0
&C0 is selected
= 1 &C1 is selected
Bit 6,7
Reserved
S22*
Bit-mapped
register
-
0-255
-
Bit
0,1,2,3
Reserved
Bit 6-4
=
000 X0 is selected
= 001 Reserved
= 010 Reserved
= 011 Reserved
=
100 X1 is selected
Register
Function
Default Range
Units
