TOSHIBA 6F3A4508

- 17 -

[6-3] Bit detail description

This function loads and writes data (sequence data etc.) inside the drive equipment.
It displays and writes in bit units.

Select Drive Tool/Data Control/Bit from the menu bar

or click the command button

to select. The following window appears.

Figure 6.3.1 Bit window

To load the sequence data BLR1, first place the cursor on the ? symbol at the top left box and
click.
Then the symbol selection list appears.
