300X CompactFlash Card

Transcend Information Inc.

V1.1

83

SMART Data Structure

BYTE

F / V

Decription

0-1

X

Revision code

2-361

X

Vendor specific

362

V

Off line data collection status

363

X

Self-test execution status byte

364-365

V

Total time in seconds to complete off-line data collection activity

366

X

Vendor specific

367

F

Off-line data collection capability

368-369

F

SMART capability

370

F

Error logging capability

7-1 Reserved

0 1=Device error logging supported

371

X

Vendor specific

372

F

Short self-test routine recommended polling time (in minutes)

373

F

Extended self-test routine recommended polling time (in minutes)

374

F

Conveyance self-test routine recommended polling time (in minutes)

375-385

R

Reserved

386-395

F

Firmware Version/Date Code

396-397

F

Number of initial invalid block (396=MSB, 397 =LSB)

398-399

V

Number of run time bad block (398=MSB, 399 =LSB)

400

V

Number of spare block

511

V

Data structure checksum

F=the content (byte) is fixed and does not change.

V=the content (byte) is variable and may change depending on the state of the device or the

commands executed by the device.

X=the content (byte) is vendor specific and may be fixed or variable.

R=the content (byte) is reserved and shall be zero.
N=Nth Management Unit

* 4 Byte value : [MSB] [2] [1] [LSB]


Above technical information is based on CFA standard data and tested to be reliable. However, Transcend makes no
warranty, either expressed or implied, as to its accuracy and assumes no liability in connection with the use of this
product. Transcend reserves the right to make changes in specifications at any time without prior notice.
