Input Power
Input Leakage Current
Input Characteristics for UDMA mode >4
In UDMA modes greater than 4, the following characteristics apply. Voltage output high and low values shall be met
at the source connector to include the effect of series termination.
Table: Input Characteristics (UDMA Mode > 4)
Parameter
Symbol
MIN
MAX
Units
DC supply voltage to drivers
V
DD3
3.3 –8% 3.3% + 8% Volts
Low to high input threshold
V+
1.5
2.0
Volts
High to low input threshold
V-
1.0
1.5
Volts
Difference between input thresholds:
((V+
current value
) - (V-
current value
))
V
HYS
320
Volts
Average of thresholds:
((V+
current value
) + (V-
current value
))/2
V
THRAVG
1.3
1.7
Volts
Output Drive Type
