5.4 Additional Cameras
Extra fixed Cameras
You can connect extra fixed cameras to your system, for example, a whiteboard camera. Connect
the video output of the additional camera to one of the available Video inputs on the system.
Multiple controllable Cameras
Attaching multiple cameras to one system expands visibility and is useful in large group
applications.
The system is able to control up to 4 WAVE II -cameras. Optional WAVE II cameras are supplied
with the necessary cabling. In addition, an external power supply for the camera is included.
WAVE II -camera number two must be connected to video input 2. Camera number three must be
connected to video input 3, and so forth.
The maximum length of the camera cable for multiple cameras supported by TANDBERG is 20 m
(65 ft).
