214
Range, menu
adjustable input gain 22.5 dB (16 steps of
1.5 dB) 22.5 dB (16 steps of
1.5 dB)
Phantom power
voltage 24 V +/- 5% -
Phantom power
resistor, pin 2 1200 ohms -
Phantom power
resistor, pin 3 1200 ohms -
Max phantom power
current pr mic 12 mA
-
3 Audio Outputs:

1 output (line level) via RCA connector providing audio from far end, in addition to dial
tones. This output also supports S/PDIF. S/PDIF (Sony/Philips Digital Interface) is used
by the Digital Natural Audio module.

1 AUX output (line level) via RCA connector providing a mixed signal between audio from
the local side (except from the AUX input) and audio from the far end. This output is
intended for connection to a telephone add-on system. When system is configured as
stereo, this output will provide the left stereo information.

1 VCR output (line level) via RCA connector providing a mixed signal between audio from
the local side (except from the VCR input) and audio from the far end. This output is
intended for connection to a VCR. When system is configured as stereo, this output will
provide the right stereo information.
Audio output connector specification:
Connector label Audio outputs
Signal type Unbalanced
Connector (codec) Female RCA/phono, sleeve-
ground, centre-signal
Output impedance 680 ohms
Maximum output level 15.3 Vpp
Minimum output level 1.15 Vpp
Range, menu adjustable
output gain 22.5 dB (16 steps of 1.5 dB)
Volume control attenuation
(audio out 1) 0 to 21 dB + mute (steps of 1.5
dB)
5.1.3 Network
Ethernet:
1 x Ethernet (RJ-45 Jack) LAN interface (10/100 Mb) up to 3 Mbps
To connect the system to a LAN, use the Ethernet cable provided by TANDBERG (or a standard
Ethernet cable).
The cable specification is:
1 ------------ 1
