2
LED behavior
Table 1 describes the behavior of the LEDs.
Table 1: IP GW blade LED behavior
LED Color Indicates
Compact Flash Activity Flashing
green One of:
the IP GW blade is booting
a configuration change has been made
the configuration is being transferred
by FTP
Console Link Green A PC is connected to the console port
Status Green The IP GW blade is operating normally
Alarm Red The IP GW blade is booting or has
developed a fault, for example:
temperature is outside normal limits
battery failure of the internal clock
Refer to the web interface for more
information about the problem (go to
Status > Health
)
System Load Green The IP GW blade is processing data. The
LEDs represent the media processing load
of the IP GW blade. The column
numbered 1 represents audio load. The
other columns represent video DSP load.
Media processing load is also displayed in
the web interface: go to
Status > General
to see the percentage load
