7
SETUP EXAMPLE: MODULATOR IN LOOP
In this setup, we operate the NOVA Modulator in
the effects loop of a combo amp (i.e., after the
preamp section, before the power amp).
• Connect your guitar to the amp’s input.
• Connect the amp’s effect send to the left
input of the NOVA Modulator.
• Connect the left output of the NOVA
Modulator to the amp’s effect return.
For best signal to noise ratio, calibrate
the pedal according to the level of the
input signal. For further information, refer
to this manual’s “Calibration” section.
