1

IMPORTANT INSTRUCTIONS

IMPORTANT

• The dishwasher drain hose must be installed

with a portion of it at least 20” (508mm) off the
cabinet floor; otherwise the dishwasher may not
drain properly.

• This dishwasher is intended for residential use

only, and should not be used in commercial food
service establishments.

• NEW INSTALLATION - If the dishwasher is a

new installation, most of the work must be done
before the dishwasher is moved into place.

• REPLACEMENT - If the dishwasher is replacing

another dishwasher, check the existing
dishwasher connections for compatibility with
the new dishwasher, and replace parts as nec-
essary.

Inspect the Dishwasher

After unpacking the dishwasher and prior to instal-
lation, thoroughly inspect the dishwasher for
possible freight or cosmetic damage. Report any
damage immediately. Cosmetic defects must be
reported within 5 days of installation.
NOTE: Do not discard any bags or items that
come with the original package until after the entire
installation has been completed.

In addition to these instructions, the dishwasher
shall be installed:
• In accordance with all local codes or, in the

absence of a local code,

• In the United States, with the National Electric

Code.

• In Canada, with the Canadian Electric Code

C22.1 -latest edition/Provincial and Municipal
codes and/or local codes.

Read these installation instructions completely
and follow them carefully.
They will save you
time and effort and help to ensure safety and
optimum dishwasher performance.

CAUTION

:

If the dishwasher is installed in a

location that experiences freezing temperatures
(e.g., in a holiday home), you must drain all the
water from the dishwasher’s interior. Water system
ruptures that occur as a result of freezing are not
covered by warranty.

WARNING - OBSERVE ALL WARNINGS AND CAUTIONS

These instructions are intended for use by qualified installers only.

IMPORTANT INSTRUCTIONS ....................... 1
Tools Needed ..................................................... 2
Materials Needed ............................................... 2
Materials Supplied .............................................. 3
Enclosure Preparation ....................................... 4
Electrical Preparation ........................................ 5
Plumbing Preparation ..................................... 6-7
Dishwasher Preparation ................................. 7-8
Door Panel Installation ....................................... 9

Table of Contents

Placing the Dishwasher ................................... 10
Securing the Dishwasher ................................ 10
Drain Hose Connection .................................... 11
Hot Water Connection ..................................... 12
Electrical Connection .................................. 13-14
Door Tension Adjustment ................................. 14
Base and Toe Panel .................................... 14-15
Final Instructions .............................................. 15
Customer Service ............................................ 16

DISHWASHER INSTALLATION INSTRUCTIONS

P/N 9000039271 (8408)
