Telit Wireless Solutions GE863-QUAD User Manual
Page 9

GE863-QUAD
GE863-PY
1vv0300715 Rev. 1 - 19/09/06
Reproduction forbidden without Telit Communications S.p.A. written authorization - All Right reserved
page 9 of 79
Pin Signal I/O
Function
Internal
Pull up
Type
59
GPIO17 I/O
GPIO
CMOS
2.8V
60
GPIO14 I/O
GPIO
-
61
RESERVED -
RESERVED
-
62
RESERVED -
RESERVED
-
63
DAC_OUT
O DAC out
64
GPIO16
I/O GPIO
CMOS 2.8V
65
RESERVED -
RESERVED
-
66
RESERVED -
RESERVED
-
67
GND -
Ground
Power
68
RESERVED -
RESERVED
-
69
GND -
Ground
Power
70
ADC_IN3
AI Analog / Digital converter input
-
71
GPIO15 I/O
GPIO
-
72
GND -
Ground
Power
73
RESERVED -
RESERVED
-
74
ADC_IN2
AI Analog / Digital converter input
-
75
RESERVED -
RESERVED
-
-
76
GPIO18 I/O
GPIO
-
77
GND -
Ground
Power
78
RESERVED -
RESERVED
-
79
GND -
Ground
Power
80
RESERVED -
RESERVED
-
(1) For the exclusive use of the Technical Support Service
(2) When activating the Easy camera these pins will not be available for other use
(3) On this pin a maximum of 10nF bypass capacitor is allowed.
(4) Available only on GE863-PY
