As a consequence of the assigned values of the resistors, the nominal values of C726 and C727 are
:
C726= 1/ (2π*4000*R719)= 7.10 *10 -9 F
C727= 1/ (2π*4000*R711)= 2,65 *10 -9 F
modified in 6,8nF (f
c1
=4181Hz ) and 2,7nF (f
c2
=3931Hz) because of commercial values .
