Universal Slot PCBs
Functional Block Diagrams
22
Strata CTX General Description 11/02
Figure 7 CTX670 System Processor and Optional Interface PCBs
Data and Speech Highway
5413
BECU Processor PCB
BBCU Processor PCB
Interface PCB
Relay Contacts, Page Output
Music Source: External Zone Page
Background Music
Door Lock Control Relay
External Zone Page Relays (4 Zones)
External Page Amplifier (600 ohm Output)
Main Distribution
Frame (MDF)
Night Bell Control Relay
Battery Charger
12V
Battery
12V
Battery
(2 or 4 Batteries)
MOH/BGM Jack
+Volume Control
BPSU672 Cabinet
Power Supply
MOH/BGM
Volume Controls
Up to Four Programmable Serial (RS-232)
Port Modular Jacks Available
ACD
(CSTA)
SMDR
Call Accounting
Amplified Page Output (3 Watts)
Remote CTX
WinAdmin PC
Local CTX
WinAdmin
BGM Mute Control Relay
Night Control Relay
Notes
1. Not required for one to two cabinets.
Required for three or more cabinets.
2. Optional. See description of License Control
earlier in this chapter.
3. Optional one or two per system.
25 Pair
Music Source 1: Background Music
and/or Music-on-hold
Music Source 2: Background Music
and/or Music-on-hold
Music Source 3: Background Music
and/or Music-on-hold
2
BEXS
1
Expansion
Module
BBMS
1
Expansion
Memory
Remote Maintenance
Modem (Built-In)
BSIS
(Optional)
Conference
SW with PAD
Ethernet
Interface
DTMF/ABR
Receivers
( Built-In )
DTMF/ABR
Receivers( Built-In )
BIOU
3
RJ45
Smart Media
Maintenance
and
Customer
Database
License
Internet
Attendant
Console (see
Fig. 8 for BATI
connection)
MOH/BGM
RCA Jacks
Hub
or
LAN
SMDI and Stratagy ES Integration
Toshiba Proprietary Soft Key LCD Link
Stratagy ES
Voice Mail
On this page, all equipment, except Stratagy ES,
connected to the system processor PCBs and
BIOU PCB is customer-supplied.
For iES32/IVP8 VM port
connection, see
Figure 9 .
