www.ti.com

ABSOLUTE MAXIMUM RATINGS

DISSIPATION RATING TABLE

RECOMMENDED OPERATING CONDITIONS

TPA3008D2

SLOS435A – MAY 2004 – REVISED JULY 2004

These devices have limited built-in ESD protection. The leads should be shorted together or the device
placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

over operating free-air temperature range (unless otherwise noted)

(1)

TPA3008D2

Supply voltage range

AV

CC

, PV

CC

-0.3 V to 20 V

Load Impedance, R

L

6

SHUTDOWN

-0.3 V to VCC + 0.3 V

Input voltage range, V

I

GAIN0, GAIN1, RINN, RINP, LINN, LINP

-0.3 V to 6 V

Continuous total power dissipation

See Dissipation Rating Table

Operating free–air temperature range, T

A

- 40

°

C to 85

°

C

Operating junction temperature range, T

J

- 40

°

C to 150

°

C

Storage temperature range, T

stg

- 65

°

C to 150

°

C

Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds

260

°

C

(1)

Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under “recommended operating
conditions” is not implied. Exposure to absolute–maximum–rated conditions for extended periods may affect device reliability.

DERATING

PACKAGE

T

A

25

°

C

θ

JC

FACTOR

T

A

= 70

°

C

T

A

= 85

°

C

(1/

θ

JA

)

PHP

4.3 W

1.14

°

C/W

(1)

34.7 mW/

°

C

(1)

2.7 W

2.2 W

(1)

Based on a JEDEC high-K PCB with the PowerPAD™ soldered to a thermal land on the
printed-circuit board. See the PowerPAD Thermally Enhanced Package application note (SLMA002).
The PowerPAD must be soldered to the PCB.

T

A

= 25

°

C (unless otherwise noted)

MIN

MAX

UNIT

Supply voltage, V

CC

PV

CC

, AV

CC

8.5

18

V

High-level input voltage, V

IH

SHUTDOWN, GAIN0, GAIN1

2

V

Low-level input voltage, V

IL

SHUTDOWN, GAIN0, GAIN1

0.8

V

SHUTDOWN, V

I

= V

CC

= 18 V

10

µA

High-level input current, I

IH

GAIN0, GAIN1, V

I

= 5.5 V, V

CC

= 18 V

1

µA

SHUTDOWN, V

I

= 0 V, V

CC

= 18 V

1

µA

Low-level input current, I

IL

GAIN0, GAIN1, V

I

= 5.5 V, V

CC

= 18 V

1

µA

High-level output voltage, V

OH

FAULT, I

OH

= 100 µA

AV

DD

- 0.8 V

V

Low-level output voltage, V

OL

FAULT, I

OL

= -100 µA

AGND + 0.8 V

V

Frequency is set by selection of ROSC and COSC

Oscillator frequency, f

OSC

200

300

kHz

(see the Application Information Section).

Operating free–air temperature, T

A

-40

85

°

C

2
