Power Requirements
Power Consumption
Output Power
Distortion
Frequency Response
Tone Controls
Inputs
Outputs
S/N Ratio
Usable Tape
Tape Speed
Wow and Flutter
Playing System
Finish
Dimensions
Weight
120V AC, 60Hz.
100W
60W
Less than 1 % (1000Hz at rated output on AUX 2 input)
TAPE : 50~15,000 Hz
AUX 2 : 50~20,000 Hz ( ± 3 dB)
BASS :100Hz±10dB
TREBLE : 10,000 Hz ±10 dB
MIC :200 1mV, balanced
AUX 1 : 50k 100m V, unbalanced
AUX 2 :600 1V, unbalanced
LINK IN (signal) :10k 150m V, unbalanced
Speaker output : 4
10 : 25V
83 : 70V
Line output : 600 1V, unbalanced
TAPE : 50 dB (Dolby NR : OFF) (AGC OFF)
60 dB (Dolby NR : ON) (AGC OFF)
MIC :60dB
Compact cassette tapes
4.76cm/sec
Less than 0.2% (WRMS)
Auto Reverse
Front panel : Aluminium, alumite process (black)/ABS resin
Case : Steel color plate (black)
420(W)x97(H)x350(D) mm (16.6 (W) x 3.8 (H) x13.8 (D) in.)
Approx. 10.3 kg (22.7 Ib.)
Power Requirements
Power Consumption
Output Power
Distortion
Frequency Response
Tone Controls
Inputs
Outputs
S/N Ratio
Usable Tape
Tape Speed
Wow and Flutter
Playing System
Finish
Dimensions
Weight
120V AC, 60Hz.
100W
30W + 30W (Stereo)
Less than 0.5% (1000 Hz at rated output on AUX 2 input)
TAPE : 50~15,000 Hz
AUX 2 : 50~20,000 Hz( ±3 dB)
BASS : 100Hz±10dB
TREBLE: 10,000 Hz ±10 dB
MIC :200 1mV, balanced
AUX 1 : 50k 100 mV, unbalanced
AUX 2 :600 1V, unbalanced
LINK IN (signal) :10k 150 mV, unbalanced
SPEAKER OUTPUT : L : 4
R :4
LINE OUTPUT : 600 1 V, unbalanced
TAPE : 50 dB (Dolby NR : OFF) AGC OFF
60 dB (Dolby NR : ON) AGC OFF
MIC :60dB
Compact cassette tapes
4.76cm/sec
Less than 0.2% (WRMS)
Auto Reverse
Front panel : Aluminium, alumite process (black)/ABS resin
Case : Steel color plate (black)
420(W) x97(H) x350(D) mm (16.6 (W) x 3.8 (H) x 13.8 (D) in.)
Approx. 8.7kg (19.2 lb.)
— 29 —
