4. CONNECTIONS
4.1. BA-800 Connection Examples
[Note]: Be sure to plug the power cord into the 120VAC wall outlet.
If the power voltage differs, the equipment may not work properly or fires or electrical shocks may
result.
PROGRAM TIMER
BA-800(for extension)
STEREO AMPLIFIER
AMPLIFIER
BA-800
120VAC, 60Hz
GROUND
