Connecting two VCRs
This connection allows you to record (dub/edit) from one VCR to
another VCR while watching a video program. You will also be able to
record from one TV channel while watching another channel.
You will need:
• two coaxial cables (one or more may be provided by your cable
company)
• two pairs of audio cables (two single audio cables for mono
VCRs)
• two video cables
ANT( 75 )
ANT-1
CHANNEL IN
ON
OFF
OUT
R
L
OUT
VIDEO
VAR
AUDIO
L/
MONO
IN
DVD IN
L
R
P
R
P
B
Y
L/ MONO
AUDIO
R
S-VIDEO
VIDEO
OUT
ANT-2
AUDIO CENTER
VIDEO 1 VIDEO 2
COLOR
STREAM
INPUT
AUDIO
R
AUDIO
VIDEO AUDIO
CH 3
L
R
CH 4
IN
OUT
VIDEO AUDIO
CH 3
L
R
CH 4
IN from ANT OUT to TV
IN
OUT
Note:
To play from the DVD player, the DVD player
and TV must use ColorStream connections.
Note:
Do not connect the same VCR to the output
and input jacks on the TV at the same time.
If you are using an S-VHS VCR, use an
S-video cable instead of a standard video
cable for better picture performance.
Do not connect a standard video cable and
an S-video cable to Video-1 (or Video-2) at
the same time or the picture performance will
be unacceptable.
To dub or edit, VCR 2 must select Line IN,
and the TV must select Video-1.
* The Audio OUT jacks can output the
sound of either the main or PIP picture
(see “Selecting the Audio OUT sound” on
page 43).
** The Video OUT jack does not output a PIP
picture.
Stereo VCR
From Antenna
TV
DVD Player with component video
VCR1
From Antenna
TV
VCR2
**
*
