Transcend Information TS32 - Manual (Page 4)

T T T S S S 3 3 3 2 2 2 / / / 6 6 6 4 4 4 / / / 1 1 1 2 2 2 8 8 8 G G G S S S S S S D D D 1 1 1 8 8 8 M M M - - - M M M
1.8” Portable Solid State Drive
Transcend Information Inc.
V1.2
4
Pin Assignments Pin Assignments Pin Assignments Pin Assignments
Pinouts (USB)
Pin No. Pin Name
01 VCC
02 USB-
03 USB+
04 VSS
Pinouts (eSATA)
Pin No. Pin Name
01 VSS
02 TX+
03 TX-
04 VSS
05 RX-
06 RX+
07 VSS
Pin Identification (USB)
Symbol Function
USB-
USB+
USB differential signal
The pair are used to transmit
Data/Address/Command
VCC USB Cable Power Detector
VSS Ground
Pin Identification (eSATA)
Symbol Function
TX+/TX-
RX+/RX-
eSATA differential signal
The two pairs are used to transmit
Data/Address/Command
VSS Ground
