1.8” Portable Solid State Drive
Transcend Information Inc.
V1.2
21
88 203Fh
V
V
V
V
V
V
V
F
F
F
F
F
F
F
Ultra DMA modes
15 Reserved
14 1 = Ultra DMA mode 6 is selected
0 = Ultra DMA mode 6 is not selected
13 1 = Ultra DMA mode 5 is selected
0 = Ultra DMA mode 5 is not selected
12 1 = Ultra DMA mode 4 is selected
0 = Ultra DMA mode 4 is not selected
11 1 = Ultra DMA mode 3 is selected
0 = Ultra DMA mode 3 is not selected
10 1 = Ultra DMA mode 2 is selected
0 = Ultra DMA mode 2 is not selected
9 1 = Ultra DMA mode 1 is selected
0 = Ultra DMA mode 1 is not selected
8 1 = Ultra DMA mode 0 is selected
0 = Ultra DMA mode 0 is not selected
7 Reserved
6 1 = Ultra DMA mode 6 and below are supported
5 1 = Ultra DMA mode 5 and below are supported
4 1 = Ultra DMA mode 4 and below are supported
3 1 = Ultra DMA mode 3 and below are supported
2 1 = Ultra DMA mode 2 and below are supported
1 1 = Ultra DMA mode 1 and below are supported
0 1 = Ultra DMA mode 0 is supported
89 0001h
F
15-8 Reserved
7-0 Time required for Normal Erase mode SECURITY ERASE UNIT command
90 0001h
F
15-8 Reserved
7-0 Time required for Enhanced Erase mode SECURITY ERASE UNIT command
91 0000h
V Current APM level value
92 FFFEh
V Master Password Identifier
93 0000h
X Hardware reset result
94 0000h
F
V
Current AAM value
15-8 Vendor’s recommended AAM value
7-0 Current AAM value
95-99 0000h
Reserved
100-103 XXXXh
X Total Number of User Addressable Logical Sectors for 48-bit commands (QWord)
104-105 0000h
Reserved
106 4000h
F
F
F
F
F
Physical sector size / logical sector size
15 Shall be cleared to zero
14 Shall be set to one
13 1 = Device has multiple logical sectors per physical sector
12 1 = Device Logical Sector longer than 256 Words
11-4 Reserved
3-0 2x logical sectors per physical sector
107-118 0000h
Reserved
