Host Communication
2-17
Getting Started
All of the signals required to interface the EVM to the host are now available
on either J13 or J15. This is simply a matter of wire-wrapping in the following
way:
J13 Wire Wrap J13
Pin No. Signal Pin No. Signal
2 NA
4 NA
6 CLKX 3 CLKX
8 TOUT 19 TOUT
10 DX 7 DX
12 FSX 11 FSX
14 NA
16 XF 1 XF
18 NA
20 NA
J15 Wire Wrap J13 Jumper
B t
J15
Pin No. Signal Pin No. Signal
Between
Pin No. Signal
1 DGND YES 2 DGND
3 DGND YES 4 DGND
5 CLKR YES 5 CLKR 6 DGND
7 DGND YES 8 DGND
9 DR YES 9 DR 10 DGND
11 FSR YES 13 FSR 12 DGND
13 DGND YES 14 DGND
15 DGND YES 16 DGND
17 NA 18 DGND
19 CLKS YES 17 CLKS 20 DGND
