Connectors
2-7
Getting Started
If SW1-1 is set to the on position, user mode is selected. In this case the user
has absolute control of the data and control signals for the ADC and DAC. With
SW1-1 in the on position, the logic that generates the control for SAM is
disabled and plays no active part in the process.
2.4 Connectors
In addition to jumpers and switches, the user also has access to various
connectors. This section details the pinout of each connector.
Reference
Designator Description
J1 Analog input option for channel 0, miniature BNC
Cells in grey are not supported (tracked) directly by this EVM.
Reference
Designator Description
Pin
Number Function
J3 Analog input option 1 Noninverting input signal to dual operational amplifier, (2) g
for universal
operational-amplifier
2 Noninverting input signal to dual operational amplifier, (2)
operational-amplifier
evaluation board, SIL
3 Inverting input signal to dual operational amplifier, (2) evaluation board, SIL
PTH not installed.
4 Inverting input signal to dual operational amplifier, (2)
5 Nonfiltered output from dual operational amplifier, (2)
6 Filtered output from dual operational amplifier, (2)
7 +V supply
8 Operational amplifier (2) shutdown signal
9 Reference voltage
10 Analog ground
11 Operational amplifier (1) shutdown signal
12 –V supply
13 Nonfiltered output from dual operational amplifier, (1)
14 Filtered output from dual operational amplifier, (1)
15 Noninverting input signal to dual operational amplifier, (1)
16 Noninverting input signal to dual operational amplifier, (1)
17 Inverting input signal to dual operational amplifier, (1)
18 Inverting input signal to dual operational amplifier, (1)
