Connectors
2-10
Reference
Designator Description
Pin
Number Function
J9 Analog input option 1 Noninverting input signal to dual operational amplifier, (2) g
for universal
operational-amplifier
2 Noninverting input signal to dual operational amplifier, (2)
operational-amplifier
evaluation board, SIL
3 Inverting input signal to dual operational amplifier, (2) evaluation board, SIL
PTH not installed.
4 Inverting input signal to dual operational amplifier, (2)
5 Nonfiltered output from dual operational amplifier, (2)
6 Filtered output from dual operational amplifier, (2)
7 +V supply
8 Operational amplifier (2) shutdown signal
9 Reference voltage
10 Analog ground
11 Operational amplifier (1) shutdown signal
12 –V supply
13 Nonfiltered output from dual operational amplifier, (1)
14 Filtered output from dual operational amplifier, (1)
15 Noninverting input signal to dual operational amplifier, (1)
16 Noninverting input signal to dual operational amplifier, (1)
17 Inverting input signal to dual operational amplifier, (1)
18 Inverting input signal to dual operational amplifier, (1)
