Connectors
2-9
Getting Started
Reference
Designator Description
Pin
Number Function
J7 EVM power 1 5 V
2 –12 V
3 0 V
4 12 V
J8 Analog output option, 1 No output g ,
26-pin DIL header
2 AGND
3 Analog output for one-channel DAC
4 AGND
5 Not connected
6 AGND
7 Not connected
8 AGND
9 Not connected
10 AGND
11 Not connected
12 AGND
13 Not connected
14 AGND
15 Not connected
16 AGND
17 Not connected
18 AGND
19 Not connected
20 AGND
21 Not connected
22 AGND
23 Not connected
24 AGND
25 Not connected
26 AGND
