PTM 2-30 B070/B071
2.4 LASER EXPOSURE
2.4.1 OVERVIEW
1. LD Unit 7. 2nd Mirror
2. Polygon Mirror Motor Control Board 8. Drum
3. Polygon Mirror Motor 9. Toner Shield Glass
4. F-Theta Lens 1 10. 1st Mirror
5. F-Theta Lens 2 11. Laser Synchronization Detector
6. BTL Lens 12. Cylindrical Lens
B070D101.WMF
10
11
12
1 2
3
4
5
6
7
8
9
