Preset Timing Chart
Item Description:
A
Total time
B
Active display area including borders
C
Active display area excluding borders
D
Left/Top border
E
Right/bottom border
F
Blanking time
G
Front porch
H
Sync-width
I
Back porch
Mode No
1
2
3
4
5
6
7
8
9
H Resolution
640
640
640
640
800
800
800
800
800
V Resolution
480
480
480
480
600
600
600
600
600
Refresh Rate
60
72
75
85
56
60
72
75
85
Hz
Pixel
25.175 31.500 31.500 36.000 36.000 40.000 50.000 49.500 56.250 MHz
Horizontal visible
640
640
640
640
800
800
800
800
800
Dots
Horizontal total
800
832
840
832
1024
1056
1040
1056
1048
Dots
Horizontal front porch
16
24
16
56
24
40
56
16
32
Dots
Horizontal sync
96
40
64
56
72
128
120
80
64
Dots
Horizontal back porch
48
128
120
80
128
88
64
160
152
Dots
Horiz blanking time
160
192
200
192
224
256
240
256
248
Dots
Vertical visible
480
480
480
480
600
600
600
600
600
Lines
Vertical total
525
520
500
509
625
628
666
625
631
Lines
Vertical front porch
10
9
1
1
1
1
37
1
1
Lines
Vertical sync
2
3
3
3
2
4
6
3
3
Lines
Vertical back porch
33
28
16
25
22
23
23
21
27
Lines
Vertical blanking time
45
40
20
29
25
28
66
25
31
Lines
Horizontal frequency
31.469 37.861 37.500 43.269 35.156 37.879 48.077 46.875 53.674 kHz
Vertical frequency
59.940 72.809 75.000 85.008 56.250 60.317 72.188 75.000 85.061 Hz
Vertical sync polarity
-
-
-
-
+
+
+
+
+
TTL
Horiz sync polarity
-
-
-
-
+
+
+
+
+
TTL
