Pin assignments for D-SUB connector (in / loop out)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1
RED
6
RED GND
11 GND
2
GREEN
7
GREEN GND
12 SDA
3
BLUE
8
BLUE GND
13 H-SYNC
4
GND
9
NC
14 V-SYNC
5
GND
10 GND
15 SCL
Pin assignments for 24-pin DVI connector (digital only)
Pin Signal Assignment
Pin Signal Assignment
Pin Signal Assignment
1
TMDS Data 2-
9
TMDS Data 1-
17 TMDS Data 0-
2
TMDS Data 2+
10 TMDS Data 1+
18 TMDS Data 0+
3
TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield
19 TMDS Data 0/5 Shield
4
TMDS Data 4-
12 TMDS Data 3-
20 TMDS Data 5-
5
TMDS Data 4+
13 TMDS Data 3+
21 TMDS Data 5+
6
DDC Clock
14 +5V Power
22 TMDS Clock Shield
7
DDC Data
15 Ground (For +5V)
23 TMDS Clock +
8
No Connect
16 Hot Plug Detect
24 TMDS Clock -
RGB/DVI
Refresh Horizontal Vertical
V-Sync
H-Sync
Mode
Rate
Frequency Frequency Polariy
Polarity
Dot rate
No.
Resolution
(Hz)
(kHz)
(Hz)
(TTL)
(TTL)
(MHz)
1
640(VGA)×480
60
31.469
59.940
-
-
25.175
2
640(VGA)×480
72
37.861
72.809
-
-
31.500
3
640(VGA)×480
75
37.500
75.000
-
-
31.500
4
640(VGA)×480
85
43.269
85.008
-
-
36.000
5
800(SVGA)×600
56
35.156
56.250
+
+
36.000
6
800(SVGA)×600
60
37.879
60.317
+
+
40.000
7
800(SVGA)×600
72
48.077
72.188
+
+
50.000
8
800(SVGA)×600
75
46.875
75.000
+
+
49.500
9
800(SVGA)×600
85
53.674
85.061
+
+
56.250
10
1024(XGA)×768
60
48.364
60.004
-
-
65.000
11
1024(XGA)×768
70
56.476
70.069
-
-
75.000
12
1024(XGA)×768
75
60.023
75.029
+
+
78.750
13
1024(XGA)×768
85
68.677
84.997
+
+
94.500
14
1280(SXGA)×1024 60
63.981
60.020
+
+
108.00
15*
1280(SXGA)×1024 75
79.976
75.025
+
+
135.00
16*
1280(SXGA)×1024 85
91.146
85.024
+
+
157.50
18
720(DOS)×400
70
31.469
70.087
+
-
28.322
19
640(VGA)×480
50
31.469
50.030
-
-
25.175
20*
1280(HDTV)×720p 60
45.000
60.000
+
+
74.250
21*
1920(HDTV)×1080i 60(i)
33.750
60.000
+
+
74.250
22
640(VGA)×350
70
31.469
70.087
-
+
25.175
23
852(WGA)×480
60
31.413
59.835
-
-
30.000
* These modes are not supported in DVI mode.
