Data Sheet: Belleta
®
iEA Series –Single Output Eighth Brick
©2004 TDK Innoveta® Inc.
iEAFullDatasheet 032707 3/29/2007 Revision 2.0
℡
(877) 498-0099
4/41
Absolute Maximum Ratings:
Stress in excess of Absolute Maximum Ratings may cause permanent damage to the device.
Input Characteristics:
Unless otherwise specified, specifications apply over all Rated Input Voltage, Resistive Load, and Temperature conditions.
Characteristic
Min
Typ
Max
Unit
Notes & Conditions
Operating Input Voltage
36
48
75
Vdc
Maximum Input Current
---
---
4
A
Vin = 0 to Vin,max
Turn-on Voltage
---
33
---
Vdc
Turn-off Voltage
26
30
---
Vdc
Hysteresis
0.5
3
---
Vdc
Startup Delay Time from application of input
voltage
---
35
---
mS
Vo = 0 to 0.1*Vo,nom;
on/off =on,
Io=Io,max, Tc=25˚C
Startup Delay Time from on/off
---
35
---
mS
Vo = 0 to 0.1*Vo,nom; Vin = Vi,nom,
Io=Io,max,Tc=25˚C
Output Voltage Rise Time
---
50
---
mS
Io=Io,max,Tc=25˚C, Vo=0.1 to 0.9*Vo,nom
Inrush Transient
---
---
0.2
A
2
s
Input Reflected Ripple
---
15
---
mApp
See input/output ripple and noise
measurements figure; BW = 20 MHz
Input Ripple Rejection
---
55
---
dB
@120Hz
Caution: The power modules are not internally fused. An external input line normal blow fuse with a
maximum value of 10A is required, see the Safety Considerations section of the data sheet.
Characteristic
Min
Max
Unit
Notes & Conditions
Continuous Input Voltage
-0.5
80
Vdc
Transient Input Voltage
---
100
Vdc
100mS max.
Isolation Voltage
---
1500
Vdc
Storage Temperature
-55
125
˚C
Operating Temperature Range (Tc)
-40
125
˚C
Measured at the location specified in the thermal
measurement figure. Maximum temperature varies
with model number, output current, and module
orientation – see curve in thermal performance
section of the data sheet.
