TDK Belleta iEA Series - Manual (Page 13)

Data Sheet: Belleta ® iEA Series –Single Output Eighth Brick
©2004 TDK Innoveta® Inc.
iEAFullDatasheet 032707 3/29/2007 Revision 2.0 ℡ (877) 498-0099
13/41
Electrical Characteristics (continued):
iEA48015A050V-000 through -015: 5V, 15A Output
iEA48015A050V-000 Typical Output Current Limit
Characteristics vs. Input Voltage at Ta=25 degrees. iEA48015A050V-000 Typical Output Ripple at nominal
input voltage and full load at Ta=25 degrees
iEA48015A050V-000 Typical Input Current vs. Input
Voltage Characteristics iEA48015A050V-000 Typical Output Voltage vs. Input
Voltage Characteristics
