Data Sheet: Belleta ® iEA Series –Single Output Eighth Brick
©2004 TDK Innoveta® Inc.
iEAFullDatasheet 032707 3/29/2007 Revision 2.0 ℡ (877) 498-0099
12/41
Electrical Characteristics (continued):
iEA48015A050V-000 through -015: 5V, 15A Output
iEA48015A050V-000 Typical Output Voltage vs. Load
Current at Ta = 25 degrees iEA48015A050V-001 Typical startup characteristic from
on/off at full load. Ch4 - on/off signal, Ch 1 – output
voltage
iEA48015A050V-000 Typical Output voltage response
to load step from 50% to 75% of full load with output
current slew rate of 0.1A/uS. iEA48015A050V-000 Typical Output voltage response
to load step from 50% to 75% of full load with output
current slew rate of 0.1A/uS and 5000uF load.
%
Change
of Vout
Trim
Down
Resistor
(Kohm)
%
Change
of Vout Trim Up
Resistor
(Kohm)
-5% 91.8K +5% 325K
-10% 40.8K +10% 168K
e.g. trim up 5%
Rup
5.1 5
Ч
100 5
+
( )
⋅
1.225 5 Ч
510
5
− 10.2 −




K ⋅ :=
iEA48015A050V-000 Calculated resistor values for
output voltage adjustment
4.95
4.96
4.97
4.98
4.99
5
5.01
5.02
5.03
5.04
5.05
1 2.4 3.8 5.2 6.6 8 9.4 10.8 12.2 13.6 15
Output Current (A)
O
u
tp
u
t
V
o
lt
a
g
e
(
V
)
Vin = 36V Vin = 48V Vin = 75V
