Data Sheet: Belleta
®
iEA Series –Single Output Eighth Brick
©2004 TDK Innoveta® Inc.
iEAFullDatasheet 032707 3/29/2007 Revision 2.0
℡
(877) 498-0099
2/41
Ordering information:
Product
Identifier
Package
Size
Platform
Input
Voltage
Output
Current/
Power
Output
Units
Main
Output
Voltage
# of
Outputs
Safety
Class
Feature Set
i
E
A
48
020
A
033
V
-
0
00
TDK Innoveta
Eighth-
brick
Belleta
36-75V
015 –15A
020 – 20A
025 – 25A
Amps
120 – 12V
050 – 5V
033 – 3.3V
025 – 2.5V
018 – 1.8V
015 – 1.5V
012 – 1.2V
Single
00 – Standard
Option Table:
Feature
Set
Positive Logic
On/Off
Negative Logic
On/Off
0.110” Pin
Length
0.200” Pin
Length
0.145” Pin
Length
Latching
OVP
00
X
X
01
X
X
02
X
X
03
X
X
04
X
X
05
X
X
11
X
X
X
15
X
X
X
Product Offering:
Code
Input Voltage
Output Voltage
Output
Current
Maximum
Output Power
Efficiency
iEA48007A120V
36-75V
12V
6.5A
78W
91%
iEA48015A050V
36-75V
5V
15A
75W
90%
iEA48020A033V
36-75V
3.3V
20A
66W
90%
iEA48025A025V
36-75V
2.5V
25A
62.5W
86%
iEA48025A018V
36-75V
1.8V
25A
45W
83%
iEA48025A015V
36-75V
1.5V
25A
37.5W
81%
iEA48025A012V
36-75V
1.2V
25A
30W
78%
