Data Sheet: Belleta ® iEA Series –Single Output Eighth Brick
©2004 TDK Innoveta® Inc.
iEAFullDatasheet 032707 3/29/2007 Revision 2.0 ℡ (877) 498-0099
15/41
Electrical Data:
iEA48020A033V-000 through -015: 3.3V, 20A Output
Characteristic Min Typ Max Unit Notes & Conditions
Output Voltage Initial Setpoint 3.25 3.3 3.35 Vdc Vin=Vin,nom; Io=Io,max; Tc = 25˚C
Output Voltage Tolerance 3.20 3.3 3.40 Vdc
Over all rated input voltage, load, and
temperature conditions to end of life
Efficiency --- 89.5 --- % Vin=Vin,nom; Io=Io,max; Tc = 25˚C
Line Regulation --- 2 7 mV Vin=Vin,min to Vin,max
Load Regulation --- 3 8 mV Io=Io,min to Io,max
Temperature Regulation --- 15 60 mV Tc=Tc,min to Tc,max
Output Current 1.5 --- 20 A
At loads less than Io,min the module will
continue to regulate the output voltage, but
the output ripple may increase
Output Current Limiting Threshold --- 29 --- A Vo = 0.9*Vo,nom, Tc
Short Circuit Current --- 20 --- A Vo = 0.25V, Tc = 25˚C
--- 35 100
mVpp
Output Ripple and Noise Voltage
--- 11 --- mVrms
Measured across one 1.0 uF ceramic
capacitor and a 10uF tantalum capacitor –
see input/output ripple measurement figure;
BW = 20MHz
Output Voltage Adjustment Range 90 --- 110 %Vo,nom
The trim range is reduced to 105% when
the input voltage is below 40V.
Output Voltage Sense Range --- --- 10 %Vo,nom
The sense range is reduced to 5% when the
input voltage is below 40V.
Dynamic Response:
Recovery Time
Transient Voltage
---
---
90
180
---
---
uS
mV
di/dt = 0.1A/uS, Vin=Vin,nom; load step
from 50% to 75% of Io,max
Output Voltage Overshoot during startup --- --- 165 mV Vin=Vin,nom; Io=Io,max,Tc=25˚C
Switching Frequency --- 400 --- kHz Fixed
Output Over Voltage Protection 3.75 --- 4.4 V
External Load Capacitance 100 --- 5000& uF Recommend TDK part C3225X5R0J107MT
Isolation Capacitance --- 1000 --- pF
Isolation Resistance 10 --- --- MΩ
Vref 1.225 V Required for trim calculation
& Contact TDK Innoveta for applications that require additional capacitance or very low esr
