Electrical Characteristics:
iEA48025A018V-000 through -015: 1.8V, 25A Output
iEA48025A018V-000 Typical Efficiency vs. Input
Voltage at Ta=25 degrees. iEA48025A018V-000 Typical Power Dissipation vs.
Input Voltage at Ta=25 degrees
iEA48025A018V-000 Typical Output Voltage vs. Load
Current at Ta = 25 degrees iEA48025A018V-001 Typical startup characteristic from
on/off at full load. Ch1 - on/off signal, Ch 4 – output
voltage
iEA48025A018V-000 Typical startup characteristic
from input voltage application at full load. Ch1 - input
voltage, Ch 4 – output voltage iEA48025A018V-000 Typical transient response.
Output voltage response to load step from 50% to 75%
of full load with output current slew rate of 0.1A/uS.
